Escaping the magics of the frameworks: 2. HTTP Routing

Most of the time, in a framework-based application, when I want to handle an HTTP request on a path, I have to annotate the controller class and methods. This way the framework knows, only at runtime, how to call our methods according to the annotated logic.

In this series of articles I’m replacing, magic by magic, some framework’s features until I have no more sorceries to wield. I’m doing it in baby steps, explaining the reasons why, and keeping my application working all the time.

I know, what I’m doing is an unconventional use of Spring Boot, but I could have used any other framework. I chose this one because it’s one of the most popular.

Also, it is interesting to see that Spring Boot itself offers different ways to do the same thing. So, let’s see what changes when we remove the magics in terms of readability, simplicity, expressiveness, and verbosity.

You can read about frameworks and what’s wrong with magics in the previous article. I also tackled the magical configuration. I recommend you read it, if you haven’t already. From now on I will continue where I left off with the code examples tackling the refactoring of the controllers.

Escaping the magics of the frameworks: 1. Configuration

Please this article on LinkedIn and tag me if you want to start a public conversation on this topic or contact me if you prefer to talk about it privately.

The Controller

The most common way to handle an HTTP request in Spring Boot is to use a Controller.

As you can see in the example project I listen for HTTP requests coming at the /greeting path through the GreetingController. The framework then parses the request, calls some logic to do the work, parses again the result and sends it as an HTTP response.

GreetingController.kt

@RestController
@RequestMapping("greeting")
class GreetingController(private val counterService: CounterService) {

    @GetMapping
    fun greeting(
        @RequestParam(value = "name", defaultValue = "World") name: String
    ): Greeting {
        return Greeting(counterService.incrementAndGet(), "Hello, ${name}!")
    }
}

Actually there is hardly a line without magic. So let’s try refactoring the code to make the logic more explicit.

@RequestParam

It is really necessary to have an annotation to get a parameter name from the request and use the default value World if it is not present? This is exactly what @RequestParam is doing.

What if there is a way to receive directly the request as parameter?

GreetingController.kt

    @GetMapping
    fun greeting(request: HttpServletRequest, response: HttpServletResponse): Greeting {
        val name = request.getParameter("name") ?: "World"
        return Greeting(counterService.incrementAndGet(), "Hello, ${name}!")
    }

(See the diff - tag 04-REQUEST-PARAM)

Note that the request parameter already has all the methods I need. I can also use the code to fallback to a default value.

“The code”… what an innovation! I can compile it, test it, debug it, extract it, do wathever I want in order to access anything from the request.

@RestController

This annotation is used to register the controller to the framework. It is a specialized version of @Controller. If you use it on the class you don’t need to annotate every method/endpoint with @ResponseBody beacuse it will be automagically activated (I will write about it right below).

Now, to get rid of @RestController I can do a small step. I can explicitly use those hidden annotations: @Controller on the class and @ResponseBody on the greeting method.

(See the diff - tag 05-REST-CONTROLLER)

@ResponseBody

What does ResponseBody mean? It means that the controller can return a class instance, because the framework takes that instance, wraps it in a ResponseEntity object, converts it to json, and puts it in the response body.

We can directly return the ResponseEntity class. Actually I found out there are a lot of helper methods to create a ResponseEntity in an expressive way.

GreetingController.kt

    @GetMapping
    fun greeting(request: HttpServletRequest, response: HttpServletResponse): ResponseEntity<Greeting> {
        val name = request.getParameter("name") ?: "World"
        return ok().body(Greeting(counterService.incrementAndGet(), "Hello, ${name}!"))
    }

(See the diff - tag 06-RESPONSE-BODY)

Doing this I can also choose which status I want to use as response. I used ServerResponse.ok() method to instantiate a 200 OK response.

@Controller & co.

Now I only left out the @Controller, the @RequestMapping("greeting") and the @GetMapping. These annotations are bound together so it is more practical to remove them all at once:

• I’ve already wrote about the @Controller annotation that registers the controller to the framework;
• The @RequestMapping("greeting") annotation, instead, tells the framework which route the controller is responsible for: /greeting;
• @GetMapping, at last, registers the annotated method as a controller route so that it will be called as soon as the service receives a GET request.

To reduce its magical grip on the code, I can transform the @Controller into a normal @Component, but doing so I need a more explicit way to register the routes.

Actually there is a way to register a router as a @Bean (dependency) and Spring Boot managed to provide RouterFunctionDsl class for it that also improves the readability.

Application.kt

@Configuration
@SpringBootApplication
class Application {
    @Bean
    fun router(greetingController: GreetingController): RouterFunction<ServerResponse> {
        return router {
            GET("/greeting") { greetingController.greeting(it) }
        }
    }
}

I prefer to have the routes registration in the main application component. In this way I can always start from the main and it is sure that I can be able to navigate down wherever I want to go. I’m able to understand the dependency graph and the flow of the request easily, starting from the main, following the path, looking at the controller and going down until I reach the core logic.

I also have the power of the IDE that suggests me what methods of the router I can use. Luckily Spring Boot, with RouterFunctionDsl, gives me also a simple way to define the routes: it’s just a function (ServerRequest) -> ServerResponse. For me it is really short and expressive.

Therefore I have to change the controller’s method signature to adapt it to the new one.

GreetingController.kt

@Component
class GreetingController(private val counterService: CounterService) {

    private fun greeting(request: ServerRequest): ServerResponse {
        val name = request.param("name").orElse("World")
        return ok().body(Greeting(counterService.incrementAndGet(), "Hello, ${name}!"))
    }
}

(See the diff - tag 07-ROUTING)

Routing

Now I can choose whether to stick to this implementation or move inside the controller the knowledge on which path a controller has to handle. There are pros and cons in both cases, I choose the second option for three reasons:

1. It is a responsibility of the controller to know which base path to handle
2. In the router I only need to register the controllers without knowing which routes every controller has to handle
3. I want to have my application designed as similarly as possible to the classical SpringBoot application.

So I can delegate to the controller through the routes method the routes registration of a specific controller in this way:

Application.kt

    @Bean
    fun router(greeting: GreetingController): RouterFunction<ServerResponse> {
        return router {
            greeting.routes(this)
        }
    }

In the controller I can now add the routes method. In this way I have all the controller routes coded and discoverable in one single method. I can also make all the private routes enforcing the cohesion of the component.

GreetingController.kt

@Component
class GreetingController(private val counterService: CounterService) {

    fun routes(router: RouterFunctionDsl) {
        router.GET("/greeting", ::greeting)
    }

    private fun greeting(request: ServerRequest): ServerResponse {
        val name = request.param("name").orElse("World")
        return ok().body(Greeting(counterService.incrementAndGet(), "Hello, ${name}!"))
    }
}

(See the diff - tag 08-ROUTING)

What I’ve done here is changing the way I’m interacting with the already present router: from a framework-style (with annotations) to a library-style, so I used the router as a dependency, and I took the control over the registration of the routes.

Conclusions

I’m almost halfway there, I reduced properties and controllers to just simple @Component (aka Beans or dependencies).

I kept an architecture similar to the Spring Boot one. So there is a central configuration accessible to all the components, and the controllers still have the responsibility of their routes definitions.

Have I added more code?
Yes, but the code is more explicit, and the parts I really added are only about the server port configuration and the router definition. However, I’m on the way to change them again in the next articles.

Have I added unnecessary boilerplate or complexity?
I don’t think so. It actually seems less complex to me now. It makes the flow and the dependencies of the application clearer. I can read the code without disturbing my memory to remember some conventions because I can easily navigate it back and forth.

What’s next?
I want to deal with the core magic of the framework: the Beans. To do it in an incremental way, however, I need to decouple my tests from the way the application is run in the first place.

Stay tuned :)
